  /    /  Compressed Air Storage & Treatment, Express Tank Vertical Air Receivers, Glenco Air & Power, Vertical Air Receivers  /  Express Tank V300-11-AS

Express Tank V300-11-AS

$1,595.00

Tank Volume 300 Litres
Design Pressure 1,100 kPa (160 psi)
Inlet & Outlet Ports 4 × 1-1/2 inch BSP
Diameter 490 mm
Shell Length 1,340 mm
Overall Height 1,900 mm
Weight 140 kg
Optional Extra Accessory Kit
Product Code EU V300-11-AS

Quick info

SKU: EU V300-11-AS Categories: , , ,

Description

• Designed and manufactured in accordance with the AS 1210 or GB 150 standards.
• WH&S Registered Design approved for workplace use in all Australian States and Territories.
• Convenient nozzle sizes and positions. Reinforced vessel support attachments.
• External surfaces abrasive blast cleaned and powder coated with an attractive textured finish.
• Azure Blue RAL 5009 external colour indicates compressed air content as per industry practice.
• Individually packed in a horizontal position inside a recyclable metal crate with plastic bag dust cover.



Additional information

Weight 168 kg
Dimensions 1960 × 610 × 700 mm

Specifications

Product Code Safety Valve Pressure Gauge Manual Drain Valve Auto Drain Valve


Manual Drain Valve Kit



Auto-Float Drain Valve Kit

 Pressure Flowrate Size Scale Dial Dia. Inlet Outlet Inlet Outlet
kPa psi m3/min cfm inch kPa mm inch inch inch inch
GM EU-V150-11-AS-K N/A 1,100 159 8.30 293 1/2 1,600 80 1/2 1/2 N/A N/A
GM EU-V300-11-AS-K N/A 1,100 159 8.30 293 1/2 1,600 80 1/2 1/2 N/A N/A
GM EU-V500-11-AS-K GM EU-V500-11-AS-ADK 1,100 159 8.30 293 1/2 1,600 80 1/2 1/2 1/2 1/8
GM EU-V800-11-AS-K GM EU-V800-11-AS-ADK 1,100 159 8.30 293 1/2 1,600 80 3/4 3/4 1/2 1/8
GM EU-V800-14-GB-K N/A 1,400 203 10.42 368 1/2 2,500 80 3/4 3/4 N/A N/A
GM EU-V1000-11-AS-K GM EU-V1000-11-AS-ADK 1,100 159 17.98 635 3/4 1,600 80 3/4 3/4 1/2 1/8
GM EU-V1200-11-GB-K GM EU-V1200-11-GB-ADK 1,100 159 17.98 635 3/4 1,600 80 3/4 3/4 1/2 1/8
GM EU-V2000-11-AS-K GM EU-V2000-11-AS-ADK 1,100 159 38.26 1,351 1 1,600 80 1 1 1/2 1/8
GM EU-V5150-14-GB-K N/A 1,400 203 48.03 1,696 1 2,500 80 1 1 N/A N/A

Download

Express Tank vertical air receivers are designed and manufactured to the highest quality standards for safe and reliable use in industrial compressed air systems. This off-the-shelf range includes the most popular sizes from 150 to 5,150 litres that are finish-painted and packed ready for dispatch.

Download Brochure
